Tata Hitachi EX 70 Super Plus

star

5

Ex-Showroom Price

₹ 30 L - 32 L

Diesel

Diesel

7000 kg

7000 kg

4150 mm

4150 mm

Download Tata Hitachi EX 70 Super Plus Brochure

Download Tata Hitachi EX 70 Super Plus brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Tata Hitachi EX 70 Super Plus

Engine Power

Engine Power

55 HP

Operating Weight

Operating Weight

7000 kg

Bucket capacity

Bucket capacity

0.68 Cu.m

Hydraulic system

Hydraulic system

60 L/min

Maximum Digging Depth

Maximum Digging Depth

4150 mm

Boom Height

Boom Height

3.72 m

About Tata Hitachi EX 70 Super Plus Overview

Tata Hitachi EX 70 Super Plus is a popular excavator in the construction vehicle industry. The price of this excavator starts from ₹ 30 Lakh and it goes up to ₹ 32 Lakh. Moreover The max digging depth...

Tata Hitachi EX 70 Super Plus Specifications & Features

Engine

Engine ModelTATA‑497 NA
Gross Power43 kW
Net Power41 kW
Engine Power55 HP
Displacement3000 cc
Number of Cylinders4 Nos
Rated RPM2100 rpm
Emission StandardBS IV
Max Torque186 Nm
Fuel TypeDiesel

Operating Weights

Operating Weight7000 kg
Machine Weight7000 kg
Counterweight1212 kg
Ground Pressure31.4 kPa

Hydraulic System

Main Pump TypeVariable Pump
Maximum Hydraulic Flow60 L/min
Maximum System Pressure34 bar
Hydraulic Oil Capacity42 litres
Auxiliary Hydraulic Flow32 L/min

Working Range

Maximum Digging Depth4150 mm
Maximum Vertical Wall Digging Depth3500 mm
Maximum Reach at Ground Level6160 mm
Maximum Dumping Height5470 mm
Maximum Cutting Height7550 mm
Boom Length3.720 m
Arm Length1620 mm
Bucket Breakout Force52 kN
Arm Tear-out Force35 kN

Tata Hitachi EX 70 Super Plus EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹64,509

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹29,00,000
Interest Amount (12 %)₹9,70,534
Total Amount Payable₹38,70,534

Tata Hitachi EX 70 Super Plus Pros and cons

like

Pros

  • Good power for size: 55 HP is respectable for a 7‑ton class — strong for medium earthmoving.
  • Decent boom height & reach: ~7.5 m cutting height gives flexibility in loading trucks/stockpiles
  • Relatively simple to operate & maintain: Tata Hitachi’s wide dealer network in India
    • dislike

    Cons

  • Engine & power limitations: While adequate, may struggle with very heavy digging/rocky conditions vs larger excavators.
  • Maintenance access & parts cost: Some owners report that accessing components for service can be tricky, and genuine parts aren’t cheap.
  • Stability on uneven ground: Can feel less stable in very uneven terrains compared to larger machines.

    • Download Tata Hitachi EX 70 Super Plus Brochure PDF

    Download Tata Hitachi EX 70 Super Plus brochure online. Check out the Tata Hitachi EX 70 Super Plus PDF brochure at Only Heavy with all features and specifications.

    Tata Hitachi EX 70 Super Plus Uses

    uses

    Excavation

    uses

    Digging

    uses

    Loading

    uses

    Construction

    uses

    Material handling

    uses

    Trenching

    Tata Hitachi EX 70 Super Plus Loan Offers
