Tata Hitachi EX 215LCQ

star

5

Ex-Showroom Price

₹ 63 L - 64.98 L

Diesel

Diesel

21250 kg

21250 kg

5910 mm

5910 mm

Download Tata Hitachi EX 215LCQ Brochure

Download Tata Hitachi EX 215LCQ brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Tata Hitachi EX 215LCQ

Engine Power

Engine Power

133 HP

Operating Weight

Operating Weight

21250 kg

Bucket capacity

Bucket capacity

1 Cu.m

Hydraulic system

Hydraulic system

221 L/min

Maximum Digging Depth

Maximum Digging Depth

5910 mm

Boom Height

Boom Height

9 m

About Tata Hitachi EX 215LCQ Overview

Tata Hitachi EX 215LCQ is the finest construction equipment model for digging & demolition tasks. The advanced features & pricing of this EX 215LCQ makes this model a worthwhile purchase. EX 215LCQ ha...

Tata Hitachi EX 215LCQ Specifications & Features

Engine

Engine ModelCummins 6BT5.9C diesel
Gross Power97 kW
Net Power97 kW
Engine Power133 HP
Displacement5900 cc
Number of Cylinders6 Nos
Rated RPM2000 rpm
Emission StandardBS III
Max Torque537 Nm
Fuel TypeDiesel

Operating Weights

Operating Weight21250 kg
Machine Weight21250 kg
Counterweight4525 kg
Ground Pressure44 kPa

Hydraulic System

Main Pump TypeVariable displacement axial piston pumps
Maximum Hydraulic Flow442 L/min
Maximum System Pressure279 bar
Hydraulic Oil Capacity220 litres
Auxiliary Hydraulic Flow67 L/min

Working Range

Maximum Digging Depth5910 mm
Maximum Vertical Wall Digging Depth5050 mm
Maximum Reach at Ground Level9060 mm
Maximum Dumping Height6230 mm
Maximum Cutting Height8990 mm
Boom Length5.680 m
Arm Length2220 mm
Bucket Breakout Force107.9 kN
Arm Tear-out Force110.8 kN

Tata Hitachi EX 215LCQ EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,37,916

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹62,00,000
Interest Amount (12 %)₹20,74,935
Total Amount Payable₹82,74,935

Tata Hitachi EX 215LCQ Pros and cons

like

Pros

  • Powered by a robust Cummins engine (131–133 PS) with proven reliability and good torque delivery.
  • Nearly 9 m cutting height and over 9 m reach make it versatile for trenching, truck loading and general excavation.
  • Hitachi’s original hydraulic system offers fast, smooth combined operations — e.g., travel + boom/arm, swing + boom — boosting productivity.
    • dislike

    Cons

  • At ~21.25 t operating weight, it’s less nimble than smaller excavators in tight urban sites.
  • Big engines with high hydraulic output can use more fuel in continuous heavy cycles vs lighter machines.
  • Exact max torque and emission standard details aren’t readily available in public spec sheets — dealers usually provide full PDFs on request.

    • Download Tata Hitachi EX 215LCQ Brochure PDF

    Download Tata Hitachi EX 215LCQ brochure online. Check out the Tata Hitachi EX 215LCQ PDF brochure at Only Heavy with all features and specifications.

    Tata Hitachi EX 215LCQ Uses

    uses

    Excavation

    uses

    Digging

    uses

    Loading

    uses

    Construction

    uses

    Material handling

    uses

    Trenching

    Tata Hitachi EX 215LCQ Loan Offers
