Kobelco SK520 XD LC-10

star

4

Ex-Showroom Price

₹ 80 L - 90 L

Diesel

Diesel

51200 kg

51200 kg

6820 mm

6820 mm

Download Kobelco SK520 XD LC-10 Brochure

Download Kobelco SK520 XD LC-10 brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of Kobelco SK520 XD LC-10

Engine Power

Engine Power

344 HP

Operating Weight

Operating Weight

51200 kg

Bucket capacity

Bucket capacity

2100 Cu.m

Hydraulic system

Hydraulic system

2 L/min

Maximum Digging Depth

Maximum Digging Depth

6820 mm

Boom Height

Boom Height

6 m

About Kobelco SK520 XD LC-10 Overview

The Kobelco SK520XDLC‑10 is a heavy‑duty hydraulic excavator built for large‑scale construction, mining, quarrying and earthmoving applications. It’s part of Kobelco’s XD (Xtra Durability) series — a ...

Kobelco SK520 XD LC-10 Specifications & Features

Engine

Engine ModelHINO P11C-WF
Gross Power257 kW
Net Power257 kW
Engine Power344 HP
Displacement10,520 cc
Number of Cylinders6 Nos
Rated RPM1850 rpm
Emission StandardBS IV
Max Torque1470 Nm
Fuel TypeDiesel

Operating Weights

Operating Weight51200 kg
Machine Weight51,200 kg
Counterweight4200 kg
Ground Pressure88 kPa

Hydraulic System

Main Pump TypeTwo variable displacement piston pumps + one gear pump
Maximum Hydraulic Flow2 × 370 L/min
Maximum System Pressure350 bar
Hydraulic Oil Capacity631 litres
Auxiliary Hydraulic Flow180 L/min

Working Range

Maximum Digging Depth6820 mm
Maximum Vertical Wall Digging Depth6110 mm
Maximum Reach at Ground Level9800 mm
Maximum Dumping Height7000 mm
Maximum Cutting Height9700 mm
Boom Length6.500 m
Arm Length2.6 mm
Bucket Breakout Force282 kN
Arm Tear-out Force239 kN

Kobelco SK520 XD LC-10 EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹1,75,731

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹79,00,000
Interest Amount (12 %)₹26,43,868
Total Amount Payable₹1,05,43,868

Kobelco SK520 XD LC-10 Pros and cons

like

Pros

  • large bucket capacity
  • Good swing speed and travel metrics
  • Efficient filtration and hydraulic systems
    • dislike

    Cons

  • Higher price range
  • Heavier operating weight
  • Larger tail swing radius

    • Download Kobelco SK520 XD LC-10 Brochure PDF

    Download Kobelco SK520 XD LC-10 brochure online. Check out the Kobelco SK520 XD LC-10 PDF brochure at Only Heavy with all features and specifications.

    Kobelco SK520 XD LC-10 Uses

    uses

    Excavation

    uses

    Digging

    uses

    Loading

    uses

    Construction

    uses

    Material handling

    uses

    Trenching
