HYUNDAI 85A SMART

Ex-Showroom Price

₹ 33 L - 35 L

Diesel

8000 kg

4150 mm

Download HYUNDAI 85A SMART Brochure

Download HYUNDAI 85A SMART brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of HYUNDAI 85A SMART

Engine Power

76 HP

Operating Weight

8000 kg

Bucket capacity

0.7 Cu.m

Hydraulic system

75.6 L/min

Maximum Digging Depth

4150 mm

Boom Height

3.7 m

About HYUNDAI 85A SMART Overview

The Hyundai 85A SMART is a medium‑class hydraulic crawler excavator designed for general construction, civil works, agricultural earthmoving, and utility digging tasks. It delivers a balanced mix of p...

HYUNDAI 85A SMART Specifications & Features

Engine

Engine ModelKirloskar 4R1040NA diesel

Gross Power56.7 kW (76 hp) @ 2200 kW

Net Power56.7 kW (76 hp) @ 2200 kW

Engine Power76 HP

Displacement6700 cc

Number of Cylinders6 Nos

Rated RPM2200 rpm

Emission StandardStage III

Max Torque289 Nm

Fuel TypeDiesel

Operating Weights

Operating Weight8000 kg

Machine Weight8000 kg

Counterweight4200 kg

Ground Pressure26 kPa

Hydraulic System

Main Pump TypeTwo variable-displacement piston pumps

Maximum Hydraulic Flow151.2 L/min

Maximum System Pressure280 bar

Hydraulic Oil Capacity130 litres

Auxiliary Hydraulic Flow180 L/min

Working Range

Maximum Digging Depth4150 mm

Maximum Vertical Wall Digging Depth3200 mm

Maximum Reach at Ground Level6190 mm

Maximum Dumping Height5179 mm

Maximum Cutting Height7260 mm

Boom Length3.700 m

Arm Length1670 mm

Bucket Breakout Force51 kN

Arm Tear-out Force39 kN

HYUNDAI 85A SMART EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹71,182

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount	₹32,00,000
Interest Amount (12 %)	₹10,70,934
Total Amount Payable	₹42,70,934

HYUNDAI 85A SMART Pros and cons

Pros

Strong Fuel Efficiency & Low Operating Cost

Reliable Performance & Resale Value

Comfortable Operator Experience

Cons

Not as Feature‑Rich as Premium Brands

Parts & Support Variability in Remote Areas

Operator Training May Be Needed
