CAT 323D3

star

4

Ex-Showroom Price

₹ 44 L - 46 L

Diesel

Diesel

22800 kg

22800 kg

6300 mm

6300 mm

Download CAT 323D3 Brochure

Download CAT 323D3 brochure online. Check out the PDF brochure at Only Heavy with all features and specifications.

Key Specs of CAT 323D3

Engine Power

Engine Power

151 HP

Operating Weight

Operating Weight

22800 kg

Bucket capacity

Bucket capacity

1.2 Cu.m

Hydraulic system

Hydraulic system

400 L/min

Maximum Digging Depth

Maximum Digging Depth

6300 mm

Boom Height

Boom Height

5.7 m

About CAT 323D3 Overview

The Cat 323D3 is a medium‑sized hydraulic excavator engineered for high‑production, heavy‑duty applications such as earthmoving, trenching, construction, quarry work, and infrastructure projects. It c...

CAT 323D3 Specifications & Features

Engine

Engine ModelCAT C7.1
Gross Power152 kW
Net Power143 kW
Engine Power151 HP
Displacement7010  cc
Number of Cylinders6 Nos
Rated RPM1700 rpm
Emission StandardUN R96 Stage II
Max Torque900 Nm
Fuel TypeDiesel

Operating Weights

Operating Weight22800 kg
Machine Weight22800 kg
Counterweight1020 kg
Ground Pressure46.8 kPa

Hydraulic System

Main Pump TypeVariable Displacement
Maximum Hydraulic Flow430 L/min
Maximum System Pressure343 bar
Hydraulic Oil Capacity276 litres
Auxiliary Hydraulic Flow129 L/min

Working Range

Maximum Digging Depth6300 mm
Maximum Vertical Wall Digging Depth4351 mm
Maximum Reach at Ground Level6431 mm
Maximum Dumping Height6962 mm
Maximum Cutting Height7542 mm
Boom Length5.7 m
Arm Length2900 mm
Bucket Breakout Force76 kN
Arm Tear-out Force65 kN

CAT 323D3 EMI Calculator

Vehicle Price

Ex-showroom price can not be less than down payment

Down Payment

Interest Rate (%)

Loan Tenure (Months)

EMI

₹95,651

per month

Note: The EMI amount shown is based on the ex-showroom price, with a 20% down payment, a 12% interest rate, and a 60-months tenure. You can adjust these values to calculate an EMI that fits your budget.

Principal Amount₹43,00,000
Interest Amount (12 %)₹14,39,068
Total Amount Payable₹57,39,068

CAT 323D3 Pros and cons

like

Pros

  • High Performance & Productivity
  • Large bucket capacity (≈1.20 m³)
  • Fuel Efficiency
    • dislike

    Cons

  • High Operating Weight
  • Fuel Efficiency vs Smaller Models
  • Advanced Features Not Fully Standard

    • Download CAT 323D3 Brochure PDF

    Download CAT 323D3 brochure online. Check out the CAT 323D3 PDF brochure at Only Heavy with all features and specifications.

    CAT 323D3 Uses

    uses

    Excavation

    uses

    Digging

    uses

    Loading

    uses

    Construction

    uses

    Material handling

    uses

    Trenching

    CAT 323D3 Loan Offers
